Steam pressure reducing valve, GS cast iron body (EN-GJS-400-18), stainless steel internal parts. PS : 17 bar - TS : 210°C. Rangeability : 10/1. Locking device in position. G thread.
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| DN | DN15 - 1/2'' |
| Face to Face (mm) | 375.0 |
| Kv (m³/h) | 1.5 |
| Body material | Ductile iron |
| Downstream pressure range (bar) | 0.14 / 1.7 |
| PS (bar) | 17 |
| Connections | BSP FF |
| TS max (°C) | 210 |
| TS min (°C) | -10 |
| Warranty period | 1 year |
| CE | Excluded (Article 4. §3) |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Ductile iron DN15 - 1/2'' 0.14 / 1.7 | 158041A | S1013109 |
€244.04
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN15 - 1/2'' 1.4 / 4 | 158042A | S1013110 |
€244.04
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN15 - 1/2'' 3.5 / 8.6 | 158043A | S1013111 |
€244.04
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN20 - 3/4'' 0.14 / 1.7 | 158051A | S1013112 |
€277.70
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN20 - 3/4'' 1.4 / 4 | 158052A | S1013113 |
€277.70
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN20 - 3/4'' 3.5 / 8.6 | 158053A | S1013114 |
€277.70
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN25 - 1'' 0.14 / 1.7 | 158061A | S1013115 |
€339.41
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN25 - 1'' 1.4 / 4 | 158062A | S1013116 |
€339.41
(excl. btw)
|
add to cart |
| BSP FF Ductile iron DN25 - 1'' 3.5 / 8.6 | 158063A | S1013117 |
€339.41
(excl. btw)
|
add to cart |
