The 703 XS V-port ball valve features a three-piece stainless steel body, designed for precise flow control in various industrial applications. Ideal for fluid regulation, it offers durability and reliable performance with a V-shaped port
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| Shaft/stem matérial | Stainless steel 316 |
| ATEX compatible | Yes |
| Flow rate coefficient CV (gpm) | 11.8 |
| DN | DN15 - 1/2'' |
| Face to Face (mm) | 75.0 |
| Kv (m³/h) | 5.1 |
| Body material | Stainless steel CF8M (1.4408) |
| Number of ways | 2 |
| Packing gland | Graphite |
| PS (bar) | 137 |
| Connections | BSP FF |
| TS max (°C) | 180 |
| TS min (°C) | -30 |
| Warranty period | 1 year |
| CE | Risk category III |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' BSP FF 5.1 | 271372V3 | S1007848 |
€237.99
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' BSP FF 10.1 | 271372V6 | S1007849 |
€237.99
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' BSP FF 6.8 | 271373V3 | S1007850 |
€248.80
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' BSP FF 14.5 | 271373V6 | S1007851 |
€248.80
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' BSP FF 13.7 | 271374V3 | S1007852 |
€273.11
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' BSP FF 24.5 | 271374V6 | S1007853 |
€273.11
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 BSP FF 29.3 | 271376V3 | S1007854 |
€365.07
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 BSP FF 47.9 | 271376V6 | S1007855 |
€365.07
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' BSP FF 38.4 | 271377V3 | S1007856 |
€605.76
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' BSP FF 81.4 | 271377V6 | S1007857 |
€605.76
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' Welding BW 5.1 | 271382V3 | S1007858 |
€237.99
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' Welding BW 10.1 | 271382V6 | S1007859 |
€237.99
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' Welding BW 6.8 | 271383V3 | S1007860 |
€248.80
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' Welding BW 14.5 | 271383V6 | S1007861 |
€248.80
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' Welding BW 13.7 | 271384V3 | S1007862 |
€273.11
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' Welding BW 24.5 | 271384V6 | S1007863 |
€273.11
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 Welding BW 29.3 | 271386V3 | S1007864 |
€365.07
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 Welding BW 47.9 | 271386V6 | S1007865 |
€365.07
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' Welding BW 38.4 | 271387V3 | S1007866 |
€605.76
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' Welding BW 81.4 | 271387V6 | S1007867 |
€605.76
(excl. btw)
|
add to cart |
