Body and ball in stainless steel 1.4408, ball in V 60°. Fire safe. PTFE-stainless steel seats. PS: 40 bar up to DN50, 16 bar above. Electric actuator type SA/NA PCU. Control: 4-20 mA.
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| Delta P (bar) | 10 |
| Opening device/signal | 4-20 mA / 0-10 V |
| DN | DN65 - 2''1/2 |
| Protection index (IP) | IP 67 |
| Kv (m³/h) | 150.00 |
| Body material | Stainless steel CF8M (1.4408) |
| Number of ways | 2 |
| PS (bar) | 16 |
| Connections | Flanged PN16 |
| Anti-condensation heater | Standard |
| Positive safety | No |
| Function | Regulation |
| Electric actuator type | SA05 PCU |
| Electric actuator series | SA/NA series |
| TS max (°C) | 230 |
| TS min (°C) | -20 |
| Warranty period | 1 year |
| CE | Risk category III |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| Flanged PN16 Stainless steel CF8M (1.4408) DN65 - 2''1/2 | 516IIS065V6NA230 | S1009819 |
€3,565.80
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN80 - 3'' | 516IIS080V6NA230 | S1009820 |
€4,268.00
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN100 - 4'' | 516IIS100V6NA230 | S1009821 |
€5,475.21
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN15 - 1/2'' | 540IIS015V6SA230 | S1009822 |
€1,532.77
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN20 - 3/4'' | 540IIS020V6SA230 | S1009823 |
€1,590.61
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN25 - 1'' | 540IIS025V6SA230 | S1009824 |
€1,652.36
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN32 - 1''1/4 | 540IIS032V6SA230 | S1009825 |
€2,025.57
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN40 - 1''1/2 | 540IIS040V6NA230 | S1009826 |
€2,595.60
(excl. btw)
|
add to cart |
| Flanged PN16 Stainless steel CF8M (1.4408) DN50 - 2'' | 540IIS050V6NA230 | S1009827 |
€2,876.60
(excl. btw)
|
add to cart |
