The 379 swing check valve consists of a ductile iron body, aluminium bronze dual plates. It is suitable for heating, distribution, drainage and seawater. Lloyd's Register Type Approval for marine applications.
| Specification | Value |
|---|---|
| DN inches NPS | 2'' |
| Option certificate 3.1 | Yes |
| Mounting direction | Horizontal or vertical upward flow |
| Construction standard | API 594 |
| CE risk category | III Module H |
| EN face-to-face standard | EN 558 series 50 |
| Tightness test standard | API 598. table 6 |
| Closure member material | Bronze -Aluminium |
| Application | Heating / Sanitary / Drinking water / Air conditioning / Irrigation |
| DN | DN50 - 2'' |
| Face to Face (mm) | 54.0 |
| Fluid | Hot water / Cold water / Oil / Some acids |
| Gasket | NBR |
| Body material | Ductile iron |
| PS (bar) | 16 |
| Connections | Between flanges PN10/16 |
| Seats | NBR |
| TS max (°C) | 80 |
| TS min (°C) | -10 |
| CE | Yes |
| Obturator type | Plate |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| Between flanges PN10/16 Ductile iron Plate DN50 - 2'' | 379050 | S1011048 |
€46.37
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN65 - 2''1/2 | 379065 | S1011049 |
€53.13
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN80 - 3'' | 379080 | S1011050 |
€62.34
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN100 - 4'' | 379100 | S1011051 |
€91.33
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN125 - 5'' | 379125 | S1011052 |
€119.61
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN150 - 6'' | 379150 | S1011053 |
€193.06
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN200 - 8'' | 379200 | S1011054 |
€307.40
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN250 - 10'' | 379250 | S1011055 |
€540.63
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN300 - 12'' | 379300 | S1011056 |
€709.39
(excl. btw)
|
add to cart |
| Between flanges PN10/16 Ductile iron Plate DN350 - 14'' | 379350 | S1011057 |
€1,289.77
(excl. btw)
|
add to cart |
