The check valve with ball, series 335, in cast iron GJL-250 in conformity with the standard for lifting stations NF en 12050-4, full bore avoiding head losses, inspection hatch, F/F BSP fitting.
| Specification | Value |
|---|---|
| DN inches NPS | 1'' |
| Option certificate 3.1 | Yes |
| Mounting direction | Horizontal or vertical upward flow |
| Thread standard | ISO 228-1 |
| Tightness test standard | ISO 5208. Rate A |
| Closure member material | NBR coated aluminium |
| Lifting station standard | Yes |
| Application | Water supply and distribution network |
| DN | DN25 - 1'' |
| Face to Face (mm) | 141.0 |
| Fluid | Cold water |
| Gasket | NBR |
| Kv (m³/h) | 21.0 |
| Body material | Cast iron |
| PS (bar) | 10 |
| Connections | BSP FF |
| Seats | Cast iron |
| TS max (°C) | 70 |
| TS min (°C) | -10 |
| Warranty period | 2 years |
| Obturator type | Ball |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Cast iron Ball 1'' | 335006 | S1011121 |
€53.04
(excl. btw)
|
add to cart |
| BSP FF Cast iron Ball 1''1/4 | 335007 | S1011122 |
€53.04
(excl. btw)
|
add to cart |
| BSP FF Cast iron Ball 1''1/2 | 335008 | S1011123 |
€58.20
(excl. btw)
|
add to cart |
| BSP FF Cast iron Ball 2'' | 335009 | S1011124 |
€62.84
(excl. btw)
|
add to cart |
| BSP FF Cast iron Ball 2''1/2 | 335010 | S1011125 |
€97.76
(excl. btw)
|
add to cart |
| BSP FF Cast iron Ball 3'' | 335011 | S1011126 |
€207.16
(excl. btw)
|
add to cart |
