Bi-metallic automatic air vent, forged steel body A 105, internal stainless steel mechanism, adjustable discharge capacity and condensate temperature. PS: 32 bar, TS: 250°C, DP max: 22 bar, flanged PN40 RF.
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| Delta P (bar) | 22 |
| DN | DN15 - 1/2'' |
| Face to Face (mm) | 150 |
| Body material | Carbon steel A105 (1.0460) |
| PS (bar) | 32 |
| Connections | Flanged PN40 |
| TS max (°C) | 250 |
| Trap type | Bi-metallic |
| Warranty period | 1 year |
| CE | Excluded (Article 4. §3) |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| Flanged PN40 Carbon steel A105 (1.0460) DN15 - 1/2'' Flanged PN40 150 | 154015 | S1013218 |
€306.54
(excl. btw)
|
add to cart |
| Flanged PN40 Carbon steel A105 (1.0460) DN20 - 3/4'' Flanged PN40 150 | 154020 | S1013219 |
€306.54
(excl. btw)
|
add to cart |
| Flanged PN40 Carbon steel A105 (1.0460) DN25 - 1'' Flanged PN40 160 | 154025 | S1013220 |
€306.54
(excl. btw)
|
add to cart |
| Flanged PN40 Carbon steel A105 (1.0460) DN15 - 1/2'' Flanged PN40 170 | 154215 | S1013221 |
€306.54
(excl. btw)
|
add to cart |
| Flanged PN40 Carbon steel A105 (1.0460) DN20 - 3/4'' Flanged PN40 170 | 154220 | S1013222 |
€306.54
(excl. btw)
|
add to cart |
