Name: ARES® stainless steel actuated angle seat valve 1452 normally open BSP
SKU: 810
Price: 183.51428571429 EUR
Availability: InStock

ARES® stainless steel actuated angle seat valve 1452 normally open BSP

€183.51 (excl. btw)

The ARES Type 1452 is a stainless steel valve, normally open (NO), for all compatible media.

In stock Subject prior to sales
Categories : Overig

Documenten:

Certificate of conformity	Download
Technical datasheet	Download
Technical datasheet FR	Download

Description
Technical Specifications

Specification	Value
Option certificate 3.1	Yes
Maximum delta P (bar)	16
ATEX compatible	No
DN	DN15 - 1/2''
Face to Face (mm)	85.0
Gasket	PTFE
Kv (m³/h)	5.70
Body material	Stainless steel CF8M (1.4408)
Bearing	PTFE
Position	Normally open
PS (bar)	25
Connections	BSP FF
Control head	50
TS max (°C)	180
TS min (°C)	-10
Flow entry	Below the seat
Solenoid pilot valve ways	2/2
Warranty period	1 year
CE	Excluded (Article 4. §3)

If you have any questions about this product, please feel free to contact us.

Product Name	Product Number	EVAC Number	Price	Add to Cart
811	BSP FF Stainless steel CF8M (1.4408) 50 DN15 - 1/2''	1452304	S1000762	€183.51 (excl. btw)	add to cart
812	BSP FF Stainless steel CF8M (1.4408) 50 DN20 - 3/4''	1452305	S1000763	€184.67 (excl. btw)	add to cart
813	BSP FF Stainless steel CF8M (1.4408) 63 DN25 - 1''	1452406	S1000764	€238.69 (excl. btw)	add to cart
814	BSP FF Stainless steel CF8M (1.4408) 63 DN32 - 1''1/4	1452407	S1000765	€285.60 (excl. btw)	add to cart
815	BSP FF Stainless steel CF8M (1.4408) 110 DN50 - 2''	1452609	S1000766	€520.20 (excl. btw)	add to cart
